     Low Pass Filter DC ~ 2250MHz

     Application

    ▶Wireless communication system.

    ▶Audio processing, image and data acquisition.

    ▶Biomedical signal processing.

    ▶Radar and sensors.

    ▶It supports a one-year standard warranty.



    RF Characteristics

    Part Number

    Frequency  Range

    (MHz)

    Insertion Loss
      Max(dB)

    VSWR
      Max

    Rejection

    Connector Type

    5o271652502250SK

    DC-2250

    1.0

    1.8

    45dB @2580-8000MHz

    SMA  Female

    5o271652502250NK

    DC-2250

    1.0

    1.8

    45dB @2580-8000MHz

    N  Female

    Basic Specifications

    Dimension

    165.6*25*20mm

    Impedance

    50Ω

    Power

    100W

    Operating Temperature

    -30 ~ +70℃

    Appearance Color

    Black

    Storage Temperature

    -55 ~ +125℃

    Overall Dimension(mm, Tolerances: ±2% unless otherwise stated.)
