    136 to 520MHz 2 Way Power Divider

    5o319470 Achieve Flawless Signal Splitting and Combining with Our 136-520MHz 2-Way Power Divider



    Precision and reliability are paramount in RF signal management. Our robust 2-Way Power Divider is engineered to deliver exceptional performance across the critical 136 to 520MHz band, making it the ideal choice for a wide range of military, commercial, and public safety applications.

    This versatile component excels in both splitting a single input into two balanced outputs and combining two signals into a single output. It features a high power handling capacity of 50 Watts as a splitter and 2 Watts as a combiner, ensuring durability in demanding environments.



    Application

    • Wireless communication system.

    • Radar and satellite systems.

    • Testing and measuring equipment.

    • Other special applications: harmonic suppression, electronic      countermeasure, etc.

    • It supports a one-year standard warranty.



    Product Highlights:

    • Broad Frequency Range: 136 –      520 MHz

    • High Isolation: >18 dB      minimizes interference between ports

    • Excellent Match: VSWR <      1.35 for superior signal integrity

    • Low Loss: Insertion Loss <      1.1 dB (including 3dB theoretical split loss)

    • Outstanding Balance: ±3° phase      and ±0.8dB amplitude unbalance

    • Robust Connectivity: Your      choice of SMA or N-type connectors

    • High Power Handling: 50W      (Splitter) / 2W (Combiner)



    Ideal for land mobile radio, military communications, and signal distribution in complex systems, this power divider guarantees consistent performance. Ensure your system operates with maximum efficiency and reliability.
